The stored value display card is compliant with EMV2000 specifications, and combined with a flexible and bi-stable display for showing the message or balance in the card. It not only shows the balance information, but also keeps the message for 30 days or more. Users put the stored value display card on the card reader for exchanging, in the meanwhile the balance information or other information are shown on the display in the card. When users receive the card, they will recognize the balance of the card anywhere, anytime.
| 2. Feature |
| 2.1 General |
|
2.1.1Secure Microcontrollers for Smart Cards
- High-performance, Low-power secure AVRR Core RISC Architecture
- Compliant with EMV 2000 Specifications; PC Industry Compatible
- Compliant with VISA/Master Card PayPass Specifications
- Full Support for ISO/IEC 14443 Type A/B protocol
- Reader-to-card
•ISO/IEC Type B: 10% ASK Modulation and NRZ Bit Coding
•Baud Rates: 106Kbps, 212Kbps and 424Kbps
- Card-to-reader:
•ISO/IEC Type B: Modulation of Incoming RF Carrier by Resistive Load Switching/ Generation of 847.5KHz Subcarrier with BPSK Modulation/ NRZ data Encoding
•Baud Rates: 106Kbps, 212Kbps and 424Kbps
- Memory 64K Bytes of ROM Program Memory
- 8K Bytes of EEPROM, Including 64 OTP Bytes and 192 Bit-addressableBytes
• 1 to 64-bite Program/Erase
• 2 ms Program, 2ms Erase
• Endurance: 500,000 Write/Erase Cycles at 25 ℃
• 10 Years Data Retention
• EEPROM Erase Only Mode
• Write EEPROM without or with Auto-Erase
• 1K Bytes of RAM + 256 Bytes of DMA dedicated RAM
2.1.2 Display
- Bi-table display with 30 days image retention (Typical)
- Life time 3 years or 15,000 times update
2.1.3 Card
- Dimension: ISO 7810 compliant
- Card Body Material: PET OR PVC
2.1.4 Electrical
- Operating Voltage: 2.7V to 5.5V
- Display response time: <1500 ms (Typical)
- 13.56MHz Clock Extraction
- 6.78 MHz Internal Bus frequency
- Power-saving Modes
- Power-up Detection
- ESD Protection to ±6KV
2.1.5 RoHS compliance |
| |
| |
| 2.2 Environmental Characteristics |
- Operation Temperature:10 to 40 ℃
- Storage Temperature: -10 to 50 ℃
|
| 2.3 Security |
- Dedicated hardware for Protection Against SPA/DPA/DEMA Attacks
- Advanced Protection Against Physical Attack, Including ActiveShield
- Environmental Protection Systems
- Light Protection
- Secure Memory Management/Access Protection (Supervisor Mode)
- Security Certification Targeted: Common Criteria EAL4+, VISA,CAST
|
| |
| |
| 3.Dimensions |
|
Height (mm) : 85.46mm~85.72mm
Width (mm) : 53.92mm ~ 54.03mm
Thickness (mm) : 0.66mm~0.84mm
|
|
